Spring MVC - 單選按鈕示例

上一頁
下一頁

以下示例展示瞭如何在使用 Spring Web MVC 框架的表單中使用 RadioButton。首先，我們需要一個可用的 Eclipse IDE，並按照以下步驟開發一個基於 Spring Web 框架的動態表單 Web 應用程式：

步驟 描述
1 建立一個名為 HelloWeb 的專案，放在 com.tutorialspoint 包下，如 Spring MVC - Hello World 章節所述。
2 在 com.tutorialspoint 包下建立 Java 類 User 和 UserController。
3 在 jsp 子資料夾下建立檢視檔案 user.jsp 和 users.jsp。
4 最後一步是建立原始檔和配置檔案的內容，並匯出應用程式，如下所述。

User.java

package com.tutorialspoint;

public class User {

   private String username;
   private String password;
   private String address;
   private boolean receivePaper;
   private String [] favoriteFrameworks;
   private String gender;

   public String getUsername() {
      return username;
   }
   public void setUsername(String username) {
      this.username = username;
   }

   public String getPassword() {
      return password;
   }
   public void setPassword(String password) {
      this.password = password;
   }
   public String getAddress() {
      return address;
   }
   public void setAddress(String address) {
      this.address = address;
   }
   public boolean isReceivePaper() {
      return receivePaper;
   }
   public void setReceivePaper(boolean receivePaper) {
      this.receivePaper = receivePaper;
   }
   public String[] getFavoriteFrameworks() {
      return favoriteFrameworks;
   }
   public void setFavoriteFrameworks(String[] favoriteFrameworks) {
      this.favoriteFrameworks = favoriteFrameworks;
   }
   public String getGender() {
      return gender;
   }
   public void setGender(String gender) {
      this.gender = gender;
   }
}

UserController.java

package com.tutorialspoint;

import java.util.ArrayList;
import java.util.List;

import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.ModelAttribute;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import org.springframework.web.servlet.ModelAndView;
import org.springframework.ui.ModelMap;

@Controller
public class UserController {

   @RequestMapping(value = "/user", method = RequestMethod.GET)
   public ModelAndView user() {
      User user = new User();
	  user.setFavoriteFrameworks((new String []{"Spring MVC","Struts 2"}));
      user.setGender("M");
	  ModelAndView modelAndView = new ModelAndView("user", "command", user);
	  return modelAndView;
   }

   @RequestMapping(value = "/addUser", method = RequestMethod.POST)
   public String addUser(@ModelAttribute("SpringWeb")User user,
      ModelMap model) {
      model.addAttribute("username", user.getUsername());
      model.addAttribute("password", user.getPassword());
      model.addAttribute("address", user.getAddress());
      model.addAttribute("receivePaper", user.isReceivePaper());
	  model.addAttribute("favoriteFrameworks", user.getFavoriteFrameworks());
      model.addAttribute("gender", user.getGender());
      return "users";
   }

   @ModelAttribute("webFrameworkList")
   public List<String> getWebFrameworkList()
   {
      List<String> webFrameworkList = new ArrayList<String>();
      webFrameworkList.add("Spring MVC");
      webFrameworkList.add("Struts 1");
      webFrameworkList.add("Struts 2");
      webFrameworkList.add("Apache Wicket");
      return webFrameworkList;
   }
}

這裡，第一個服務方法 **user()**，我們在 ModelAndView 物件中傳遞了一個空的 **User** 物件，名稱為“command”，因為 Spring 框架期望一個名為“command”的物件，如果您在 JSP 檔案中使用 <form:form> 標籤。因此，當呼叫 **user()** 方法時，它會返回 **user.jsp** 檢視。

第二個服務方法 **addUser()** 將針對 **HelloWeb/addUser** URL 上的 POST 方法呼叫。您將根據提交的資訊準備模型物件。最後，服務方法將返回“users”檢視，這將導致渲染 users.jsp。

user.jsp

<%@taglib uri = "http://www.springframework.org/tags/form" prefix = "form"%>
<html>
   <head>
      <title>Spring MVC Form Handling</title>
   </head>
   <body>

      <h2>User Information</h2>
      <form:form method = "POST" action = "/HelloWeb/addUser">
         <table>
            <tr>
               <td><form:label path = "username">User Name</form:label></td>
               <td><form:input path = "username" /></td>
            </tr>
            <tr>
               <td><form:label path = "password">Age</form:label></td>
               <td><form:password path = "password" /></td>
            </tr>
            <tr>
               <td><form:label path = "address">Address</form:label></td>
               <td><form:textarea path = "address" rows = "5" cols = "30" /></td>
            </tr>
            <tr>
               <td><form:label path = "receivePaper">Subscribe Newsletter</form:label></td>
               <td><form:checkbox path = "receivePaper" /></td>
            </tr>
            <tr>
               <td><form:label path = "favoriteFrameworks">Favorite Web Frameworks</form:label></td>
               <td><form:checkboxes items = "${webFrameworkList}" path = "favoriteFrameworks" /></td>
            </tr>
            <tr>
               <td><form:label path = "gender">Gender</form:label></td>
               <td>
                  <form:radiobutton path = "gender" value = "M" label = "Male" />
                  <form:radiobutton path = "gender" value = "F" label = "Female" />
               </td>
            </tr>
            <tr>
               <td colspan = "2">
                  <input type = "submit" value = "Submit"/>
               </td>
            </tr>
         </table>
      </form:form>
   </body>
</html>

這裡，我們使用 **<form:radiobutton />** 標籤來渲染 HTML 單選按鈕。

<form:radiobutton path = "gender" value = "M" label = "Male" />
<form:radiobutton path = "gender" value = "F" label = "Female" />

它將渲染以下 HTML 內容。

<input id = "gender1" name = "gender" type = "radio" value = "M" checked = "checked"/><label for = "gender1">Male</label>
<input id = "gender2" name = "gender" type = "radio" value = "F"/><label for = "gender2">Female</label>

users.jsp

<%@taglib uri="http://www.springframework.org/tags/form" prefix="form"%>
<html>
<head>
    <title>Spring MVC Form Handling</title>
</head>
   <body>

      <h2>Submitted User Information</h2>
      <table>
         <tr>
            <td>Username</td>
            <td>${username}</td>
         </tr>

         <tr>
            <td>Password</td>
            <td>${password}</td>
         </tr>

         <tr>
            <td>Address</td>
            <td>${address}</td>
         </tr>

         <tr>
            <td>Subscribed to Newsletter</td>
            <td>${receivePaper}</td>
         </tr>

         <tr>
            <td>Favorite Web Frameworks</td>
            <td> <% String[] favoriteFrameworks = (String[])request.getAttribute("favoriteFrameworks");
               for(String framework: favoriteFrameworks) {
                  out.println(framework);
               }
            %></td>
         </tr>

         <tr>
            <td>Gender</td>
            <td>${(gender=="M"? "Male" : "Female")}</td>
         </tr>
      </table>
   </body>
</html>

完成原始檔和配置檔案的建立後，匯出您的應用程式。右鍵單擊您的應用程式，使用 **匯出 → WAR 檔案** 選項並將 **HelloWeb.war** 檔案儲存在 Tomcat 的 webapps 資料夾中。

現在，啟動您的 Tomcat 伺服器，並確保您可以使用標準瀏覽器從 webapps 資料夾訪問其他網頁。嘗試 URL – **https://:8080/HelloWeb/user**，如果您的 Spring Web 應用程式一切正常，我們將看到以下螢幕。

Spring RadioButton Form

提交所需資訊後，單擊提交按鈕提交表單。如果 Spring Web 應用程式一切正常，我們將看到以下螢幕。

Spring RadioButton Form Result
